Magneto Stator For Yamaha YB125 YB125SPD YBR125ED/3D9 YBR125ED/51D 2008-2014
Magneto Stator For Yamaha YB125 YB125SPD YBR125ED/3D9 YBR125ED/51D 2008-2014
Magneto Stator For Yamaha YB125 YB125SPD YBR125ED/3D9 YBR125ED/51D 2008-2014
Magneto Stator For Yamaha YB125 YB125SPD YBR125ED/3D9 YBR125ED/51D 2008-2014
Magneto Stator For Yamaha YB125 YB125SPD YBR125ED/3D9 YBR125ED/51D 2008-2014
Magneto Stator For Yamaha YB125 YB125SPD YBR125ED/3D9 YBR125ED/51D 2008-2014
Magneto Stator For Yamaha YB125 YB125SPD YBR125ED/3D9 YBR125ED/51D 2008-2014
Magneto Stator For Yamaha YB125 YB125SPD YBR125ED/3D9 YBR125ED/51D 2008-2014

Magneto Stator For Yamaha YB125 YB125SPD YBR125ED/3D9 YBR125ED/51D 2008-2014

Sale price$82.89
SKU: M550-A346
Quantity:

SPECIFICATIONS:
Condition: Aftermarket 100% Brand New
Quantity: 1PC
Type: Generator Stator Coil
Replacement Part Number: 3D9-H1410-10, 3D9-H1410-12

Dimensions :
Interior diameter : 36.8 mm/1.44"
Exterior diameter : 92 mm/3.62"
Pole's Thickness : 26.5 mm/1.04"
Pole's Width : 11 mm/0.43"



Magneto Stator For Yamaha YB125 YB125SPD YBR125ED/3D9 YBR125ED/51D 2008-2014



Other specifications :
Number of wires: 6
Number of pins: 6
Number of plugs: 3
Number of fixation holes: 3
Number of poles: 18

FITMENT:
For Yamaha YB125 YB125SPD 2008
For Yamaha YBR125ED/3D9 2008-2014
For Yamaha YBR125ED/51D 2012


FEATURES:
Direct replacement to your original unit
Plug-and-play, direct fit, easy installation.
Highest grade lamination materials.
Highest grade copper winding, resistant to 200 degrees Celsius.
Pick up pulsar coil included.
Connector included.
All products shipped are tested.

PACKAGE INCLUDED:
1 x Generator Stator Coil

NOTICE:
Before installing your new stator

Check the AC output of the stator.
Replace any burned or corroded connectors on stator and regulator/rectifier.
Check and repair any melted wiring.
Use hi-temp dielectric grease on all connectors
Our stator may use a different wire color code than your original.
All of the wires are installed in the correct order; please do not change any of the wiring configurations.
This stator is designed as a direct plug-in replacement and should be used as such.
When bolting stator in, always use locking compound.
If our stator includes a pickup coil, always make sure the air gap is correct upon installation.

All item pictures are accurate; if in doubt do not hesitate to compare our item to your original part.

Shipping:
Free Shipping
Handling time: Ship within 24 hours
Delivery Time: 3-7 business days

Warranty:
1. Condition: 100% Brand New
2. Warranty Period: 1 Years
3. 24-Hour Support: Provide you with timely after-sale support
